Commercial 380V 3-Phase Hardwired Rack Conveyor Dishwasher 120 Racks/Hour 26kW - DAVS124
When operating a high-volume catering establishment in bustling UK hubs like London, Manchester, or Birmingham, managing rapid tableware turnaround is essential. The Commercial 380V 3-Phase Hardwired Rack Conveyor Dishwasher 120 Racks/Hour 26kW - DAVS124 is the ultimate heavy-duty warewashing solution available through My Globel, expertly designed for demanding hospitality venues, large hotels, and institutional canteens.
At My Globel, we ensure your commercial kitchen operates at peak efficiency with reliable equipment backed by a 12 mth spare parts warranty. Order today to benefit from our prompt nationwide delivery service.
Key Features
- Stainless steel construction - Provides a durable, hygienic build quality suitable for intensive commercial use.
- Maximum washing capacity - Delivers a high-efficiency throughput of 120 racks per hour.
- Powerful spray system - Incorporates upper and lower spray washing to ensure consistent coverage and cleanliness.
- High-temperature rinse - Operates between 80–95°C to meet essential sanitation requirements.
- Right-in, left-out configuration - Optimised for specific kitchen workflows, serving as the opposite-direction version of the DAVS120.
- Adjustable conveyor speed - Offers flexible settings at 1.8, 2, or 3m/min, configured during installation to suit your specific volume needs.
- Automatic water filling - Reduces operator intervention, maintaining consistent wash tank temperatures of 50–65°C.
Product Specifications
| Brand | Adexa |
| Model | DAVS124 |
| SKU | DAVS124 |
| Category | Cleaning & Hygiene |
Dimensions & Weight
| Width | 90.00 |
| Depth | 780mm |
| Height | 1740.00 |
| Weight | 150.00 kg |
Power Supply
| Voltage | 380V / 50Hz / 3 Phase |
| Power | 26kW |
Miscellaneous
| Product Code | DAVS124 |
| Maximum throughput | 120 racks per hour |
| Rack size | 500 x 500mm |
| Total power | 26kW |
| Electrical configuration | 3PH + N + PE hardwired |
| Wash tank temperature | 50–65°C |
| Rinse water temperature | 80–95°C |
| Water consumption | 270L/hour |
| Entry opening | 540 x 400mm |
| Noise level | 65dB(A) |
| Water inlet | G 1/2" |
| Inlet pressure | 2–5 bar |
| Drain connection | Ø50mm |
| Basket Size | 500x500mm |
| Temperature (washing) | 50℃~65℃ |
| Temperature (rinsing) | 80℃~95℃ |
| Capacity | 120 Racks/h, right-in, left-out configuration |
Warranty
| Warranty | 12 mth spare parts warranty |
Ideal For
- Large-scale institutional catering in London
- High-turnover restaurant kitchens in Manchester
- Hotel banqueting and events in Birmingham
- Industrial canteen facilities across the UK
- University and school dining halls
- Hospital catering departments
Frequently Asked Questions
What is the maximum washing capacity of this dishwasher?
The dishwasher delivers a high-efficiency throughput of 120 racks per hour.
What electrical supply does this unit require?
It requires a 380V / 50Hz / 3 Phase power supply with a 3PH + N + PE hardwired configuration.
What are the wash and rinse temperature ranges?
The wash tank operates at 50–65°C, while the high-temperature rinse operates between 80–95°C.
What is the water consumption rate?
The unit consumes 270L of water per hour.
Order the Commercial 380V 3-Phase Hardwired Rack Conveyor Dishwasher 120 Racks/Hour 26kW - DAVS124 at My Globel and enjoy reliable nationwide delivery.
